VisBox-4K - Immersive 3D Display

Home > Products > Immersive Displays > VisBox > VisBox-4K

Key Features:

- 14' wide screen, rear-projection unit, only 12' deep
- 4K (4096x2160) resolution!
- Multi-use: mono, stereo, tracked stereo (VR)
- Custom configurations available, see Services page

VisBox-4K^TM

Ultra-Resolution Immersive 3D Display

Ultra-Resolution Applications
The VisBox-4K provides unparalleled stereo image quality using two native 4K resolution projectors (4096x2160)! For custom 4K displays, see the Services section.

More pictures

Other VisBox Models

VisBox-HD: 6'x3.4' screen, 1920x1080
VisBox-HD2: 8'x4.5' screen, 1920x1080
VisBox-SX8: 8'x6' screen, 1400x1050
VisBox-SX10: 10'x7.5' screen,1400x1050
VisBox-SX12: 12'x9' screen, 1400x1050

Custom: custom screen size, resolution

Multi-screen: VisCube-SX

Compare All VisBox Models

The VisBox-4K^TM model features a large 14' wide screen size and 4K (4096x2160) projectors. The result is a completely seamless and uniform extremely high resolution stereo 3D display with unmatched image quality. Like the the other VisBox^TM models, it is available either as a stand-alone 3D stereo display or as a turn-key projection-based VR system with head and wand tracking.

For more general information about VisBox systems and their applications, visit the VisBox page.

For detailed information about the 4K model, view the VisBox-4K Datasheet below. To compare the VisBox-4K to the other VisBox models, visit the VisBox Models page.

In addition to the standard VisBox models, Visbox Inc. is also available for custom hardware and software development for customers with special needs. Learn more about our capabilities on the Services page.

Have questions? Contact us.

VisBox-4K Datasheet

	System Specifications - Resolution: 4096x2160 - Screen size: 168"w x 88.5" h (190" diagonal) - Footprint: 179"w x 99"h x 145"d Includes: - Two digital 4K projectors, 5000 lumens each - Free-standing enclosure with front-surface mirror - Custom projector positioners - Infitec filters and 10 pairs of premium glasses - Video and power cabling - Installed and calibrated on-site by Visbox, Inc.
	Option: High Brightenss - Upgrade to 10,000 lumens per projector
	Option: Borderless Screen Edge - Borderless screen edge on both sides of unit - Allows multiple VisBox-4K units to be used side-by-side
	Option: VisTrack Tracking Package - VisTrack wireless optical head tracker - 1 pair tracked glasses
	Option: Ascension Tracking - Ascension Flock of Birds (FOB) with long range transmitter (ERT) - Head sensor, WANDA 3 button wand
	Option: Intersense Tracking - IS-900 PCTracker or SimTracker - MiniTrax head tracker, MiniTrax 6 button wand
	Option: Graphics Workstation - Graphics workstation with NVIDIA graphics - Software demos, applications, and development libraries
VR	Option: Turn-key VR system - Tracking package (see options above) - Graphics workstation (see above) - Speakers and amplifier

Other options are also available.
